Features:

1.Multi-Functional Testing

Equipped with capabilities for measuring DC/AC voltage, resistance, capacitance, temperature, and frequency, ZT1000R offers versatile functionality for a range of user applications.

2.Five Voltage Settings

Includes 5 distinct voltage test settings (50V, 100V, 250V, 500V, and 1000V) with precise measurement options, meeting the needs of professional-level insulation testing.

3.High-Precision Accuracy

Designed with auto-ranging and advanced circuitry to ensure accurate readings across a wide measuring range, meeting the demands of electrical professionals.

4.Large Backlit Screen

Features an easy-to-read LCD screen with backlight capabilities, making it convenient for use in low-light or complex working environments.

5.Compact, Ergonomic Design

Lightweight construction paired with a rotary switch dial for hassle-free operation and enhanced portability during fieldwork or laboratory measurements.

Specifications:

DC Voltage: 1000.0V / 199.99V / 19.999V / 1.9999V (± 0.05% + 3)

AC Voltage: 750.0V / 199.99V / 19.999V / 1.9999V (± 0.5% + 3)

Resistance: 199.99Ω / 1.9999kΩ / 19.999kΩ / 199.99kΩ / 1.9999MΩ / 19.999MΩ (± 0.3% + 3)

Capacitance: 999.9µF / 99.99µF / 9.999µF / 999.9nF / 99.99nF / 9.999mF / 99.99mF (± 2%-5%)

Frequency: 999.9kHz / 99.99kHz / 9.999kHz / 999.9Hz / 99.99Hz / 9.999Hz (± 0.1% + 2)

Temperature: -20°C ~ 1000°C (-4°F ~ 1832°F) (± 2.5% + 2)

Display Count: 19,999

Power: 3 x 14500 Lithium Batteries(not included)

Sampling Rate: 2 times per second

Dimensions: 176 x 91 x 47 mm

Weight: 330g

CE  ROHS
